Finding the Model and Serial Tag on a Panelled Sub-Zero

A panel-ready Sub-Zero hides its badge behind the cabinetmaker's work, so the kitchen tells us very little. The tag does. It carries the model and serial number, and the model number alone says the series, the width and the hinge side.

Where the tag is, series by series

Unit	Where to look
Designer column (DEC, earlier IC)	Inside the middle drawer, near the drawer guide on the side away from the hinge. On a four-drawer DEC refrigerator, behind the middle two drawers near the guide.
Designer tall and over-and-under (DET, earlier IT)	Inside the cabinet, to the left of the upper drawer.
Designer drawers (ID) and the 700 Series	Inside the cabinet, to the left of the upper drawer.
PRO 36 (PRO3650)	Inside the cabinet, to the left of the freezer drawer.
PRO 48 (PRO4850, earlier 648PRO)	Inside the cabinet, to the left of the upper freezer drawer.

Pulling the drawer out to its stop is usually enough to see it. A photo of the tag on a phone is as good as reading it out.

Reading the model number

Letters at the front name the line, the numbers give the width, and the letters after them describe the layout and features.

On the tag	Means
DEC · DET	Designer column · Designer tall
IC · IT	the same two shapes before the Designer name
30, 36 …	the width in inches
R · C · F	all refrigerator · refrigerator and freezer · all freezer
I · ID · G	ice maker · internal dispenser · glass door
/R or -RH · /L or -LH	hinged on the right · hinged on the left

So a DET3650CI is a 36-inch Designer tall unit with refrigerator, freezer and ice maker. The hinge suffix matters to us more than to most: it tells us which side the door and panel weight hang from.
